As we are factory, we can guarantee our price is first- hand.
We have professional consultants to give you the most suitable solution.
Delivery time: 1-10 days after received the payment.
We have our own R&D team.
|V.DC (Rated Voltage)||5||6||12||24||48||60|
|Pull-in Voltage||DC: ≤75% (KV)|
|Coil Power||About 0.9W ( ≤48VDC) / About 1.2W (48VDC- 60VDC)|
|Electrical Life||60000次(600 Ops/h)(1S ON 5S OFF )/NO|
|30000次(600 Ops/h)(1S ON 5S OFF )/NC|
|Mechanical Life||≥1000万次(18000 Ops/h)|
|Pit Electric Intensity||Between contacts of the same level 1000VAC 1min|
|Between the contact and the coil 4000VAC 1min|
|Temperatuer Range||-40~ 85°C|
|Vibratiou Res.||10-55HZ Double-amplitude: 1.0mm|
|Impact Res,||10G(Half-Sine Pulse: 11ms)|
|Minmum Touch Current||3V AC/DC,5mA|
|Contact Material||AgNi, AgSnO2|
